3636 6090 1224 1.5kw Advertising CNC Engraving Woodworking Machines Mini Small CNC Router for Metal Aluminum Copper Wood Acrylic Handicraft PVC

3636 6090 1224 1.5kw Advertising CNC Engraving Woodworking Machines Mini Small CNC Router for Metal Aluminum Copper Wood Acrylic Handicraft PVC

Product Description Advertising CNC Router Brief introduction 1.Whole machine is welded with seamless steel lathe bed.th
SHARE

Description

Basic Info.
Model NO. GD6090
Power Small Power
Control CNC
Drive Type Stepper Drive
Spindle Power Spindle Power
Transmission Xyz with Tbi Ball Screw
Software Environment Windows XP/7
Control Instruction G(Nc), Mmg, Plt, Eng, Dxf
Control System Nc Studio/DSP
Max Traveling Speed 6000-8000mm/Min
Tool Diameter 3, 4, 6, 12.7
Max Feeding Height <150mm(Customized)
Working Size 600*900mm
Transport Package Plywood Packing
Specification 600*900mm
Trademark Guandiao
Origin Jinan
Production Capacity 10000 Sets/Year
Product Description
Product Description
Advertising CNC Router
Brief introduction
1.Whole machine is welded with seamless steel lathe bed.the stability is excellent. not easy to deformed. to ensure the high precision.2.Imported linear Taiwan brand guide rail, ball screw. self lubricating slide block, ,making each direction force equal . to ensure that the mechanical precision and strength.3.Have the function of break-point memory,making it possible to go on working in accident (broken knife) or the next day.
the break point memory
4.The domestic well known brand water -cooling spindle, HQD brand professional design for metal carving with constant power, ensuring carving strength on metal, aluminum or copper , also can work on wood,plastic etc ,with small noise ,big cutting strength .ensuring long time mass processing.
5.Well compatibility for CAD/CAM design software, like TYPE3/Artcam/Castmate/wentai and so on.
6.Widely used and economic .for advertising,,decoration, label production, wood mold, badge and embossing mold, cookies,chocolate and candy mold, PCB. crafts scale, building model,and so on
Advertising CNC Router technical parameters
ModelGD-6090GD-1212GD-1224
working size600*900mm1200*1200mm1200*2400mm
Max feeding height<150mm(Customized)
Max traveling speed6000-8000mm/min
Tool diameter¢3,¢4,¢6,¢12.7
TransmissionXYZ with TBI ball screw
Spindle power1.5KW/2.KW(Optional)24000rpm/min, 220v/380v
Control systemNC studio/DSP
Software environmentWindows XP/7
Control instructionG(nc),mmg,plt,eng,dxf

Advertising CNC Router technical application
1.Can make cutting, carving processing to wood, plastic and marble etc. Also used in manufacture industry forcopper, iron and aluminium workpiece processing.
2.Artwork industry: Carving various characters and figures on gifts, furniture, wood articles, artworks and souvenirs. Matrix processing industry:
Applied in carving of elaborate characters and patterns, processing of small matrix
products.
3. Building model industry: Carving some elaborate small windows, fences, wall decoration patterns etc.
4.Seal industry: Carving various seals with cattle horn, plastic, wood and ink storage
Advertising CNC Router details

1.Spindle motor

Name: Spindle
Brand: HQD
Original: China,
1.5KW or 2.2KW or 3.5kw water cooling spindle. for different requirement are optional, cutting or engraving all enough,fast rotating speed,0-24000rpm/min
Each spindle with extra collect for different size bits needing .
We also supply professional metal carving spindle wih constant power, water and dust proof design, use high speed bearing ,pro-long service life ,

3636 6090 1224 1.5kw Advertising CNC Engraving Woodworking Machines Mini Small CNC Router for Metal Aluminum Copper Wood Acrylic Handicraft PVC


2.Main Features

Name: Control systemBrand: Shanghai Nc STUDIOOriginal: ChinaDomestic famous and professional system supplier,easy operation,insert on computer main box,
Other optionsl: DSP A11s or MACH 3 ALL WITH CONTROL HANDLE

3636 6090 1224 1.5kw Advertising CNC Engraving Woodworking Machines Mini Small CNC Router for Metal Aluminum Copper Wood Acrylic Handicraft PVC


3.Machine Parts

Name: Guide railBrand: Taiwan Hiwin Original: Taiwan,ChinaAdopts world brand famous square guide rail,bigger bearing, smooth transmission.high precision ,no deformation

3636 6090 1224 1.5kw Advertising CNC Engraving Woodworking Machines Mini Small CNC Router for Metal Aluminum Copper Wood Acrylic Handicraft PVC


4.Dust cloth and Omron limit

Three axis with dust cloth,prevent dust/powder into machine body,ensure high precision working ,nice looking ,humanize design
Each axis euip with Japan Omron limit,ensure CNC router safe running, avoid risk

3636 6090 1224 1.5kw Advertising CNC Engraving Woodworking Machines Mini Small CNC Router for Metal Aluminum Copper Wood Acrylic Handicraft PVC


5.3D Rotary optional

3D rotary are optional. which is suitable for 3d rotary statue carving ,like stone,wood crafts,portrait ,
This require machine with 4 axis system ,Pls consult me before ordering, we can suggest you suitable machine

3636 6090 1224 1.5kw Advertising CNC Engraving Woodworking Machines Mini Small CNC Router for Metal Aluminum Copper Wood Acrylic Handicraft PVC


Standard accessories along with the machine



Advertising CNC Router samples

Our Services
1. Delivery and Lead time
Machine will be proper packed and loaded in container, as multiple loaded to save space or wooden carton sealed for better transportation.
Machine will be tidy and clean , with anti rusty oil brushed on mechanical parts to prevent rusty on sea transportation.
A series pictures and videos will provided as machine finished for help customer understand the performance of the machine.
2.Warranty:
Machine warranty is 12 months. Machine as normal using and maintenance condition, if get any problem, will provide spare parts for free. Out of warranty, will collect the accessories cost. Technical support for maintenance or fix on time and all the time.
3. Technical support:
Manual and video illustration of the machine will be provided
24 hours online by Ali Trademanager, Skype, Email, QQ, or telephone
Technical support by email, whatsapp, wechat,imo and skype available on time.4.After sale service:
Normally the machine will sent on whole except the machine is over size to load container. so the machine arrange in production immediately after get electricity (air and water some model needed).
The video for operation will provide.
Training at our workshop or on site is available.After sale-service5.We accept the ODM,OEM

If you have other needs, please let me know
Packaging & Shipping



Company Information
Jinan Guandiao CNC Equipment Co., Ltd is an innovative enterprise engaged in research and development,production, sales and good after- sales service. The company's main products include Panel furniture CNC cutting machine, Woodworking CNC Machining Center, CNC router , Multi-head cylinder CNC engraving machine, Styrofoam CNC router, 3D scanner, Vacuum membrane press machine, Vacuum forming machine, Laser engraving and cutting machine, etc. Products applied to the panel furniture, European furniture, solid wood furniture, advertising, stone, building decoration, handicrafts, mold making, staircases column, PCB printing, automotive industry, packaging industry, shipbuilding, wood manufacturing, watches and clocks, accessories, seals and other industries.
After nearly 10 years of development, the company has a perfect technical team, clear labor division, ensuring the high quality products sent to the whole country, to the world.
We offer our customers best solutions, including product design, installation, training, aftersales service, etc. With the market development demand as the orientation, we stick to innovate and improve technology continuously, to the peak of CNC industry is our relentless drive.
At present, the company's products are sold to major and small cities and regions in China.
The company has independent import and export right, products are exported to southeast Asia, the Middle East, Africa, Europe and the United States and other places, and with its excellent quality, excellent performance and perfect after -sales serves won the customer the consistent approval.
